RCF F16XR - 16Ch Analogue Multi-FX Mixer 10xMic/4xMono/4xStereo-In
10 Mic preamp inputs, 4 mono line inputs
4 Stereo line inputs
PRO DSP FX onboard with 16 presets
Stereo recording and playback via USB port
6 single control compressors
Balanced main output +28 dB (Stereo XLR + TRS)
Two stereo output busses and 4 aux sends (2 pre, 1 pre/post, 1 post)
60 mm faders
Internal universal power supply
Designed and engineered in Italy
Specifications:
Electronic Specifications
Frequency Response: 20 Hz ÷ 20 kHz
THD+N, 20dB gain, 0dBu out <0,02
Inputs
Mic: 10
Gain Range: 0 dB ÷ -50 dB
Mic Inputs Impedance: 14 kohm
Low Cut: 80 Hz
Phantom Power +48V: Yes
Mono Line: 8
Gain Selection: 20 dB ÷ -30 dB
Line Input Impedance: 21 kohm
HI-Z Line Inputs: 1
HI-Z Line Inputs Impedance (Mohm): 1 Mohm
Stereo Line: 4
Gain Selection: 20 dB ÷ -30 dB
Stereo Line Input Impedance (kOhm) 14 kohm
Outputs
Main MIX: 1
Control Room: Yes
FX Send: 1
AUX Send: 3
AUX Output: 4
Group Out: 4
Phones: 1
Outputs Specifications
Main Out Level: 28 dBu
Aux Out Level: 28 dBu
Group Out Level: 28 dBu
Phones Out impedance (ohm): 150 ohm
Phones Out Level: 10 dBm
Compressors
RCF Compressors: n° 6 Single Control compressors on channels 1 to 6
EQ
Input Channels EQ: 1 Semi Parametric / 2 Shelving
Description: High: +/-15 dB @ 10 kHz Shelving
Mid: +/-15 dB @ Freq. sel. from 100Hz to
8kHz - Bell
Low: +/-15 dB @ 100 Hz Shelving
Auxiliary Sends
AUX: 2 PRE / 1 PRE/POST
FX POST: 1
Internal Effects
Send Effects: 1
USB Audio
Type: B
Play trk: 2
Rec trk: 2
Supported Sample Rate: 44.1, 48.0
Other Features
Footswitch: Yes
Electrical Specifications
Power supply: Internal
Voltage requirements: 100 V - 240 V
Power consumption (MAX): 30 W
Standard Compliance
CE marking: Yes
Physical Specifications
Cabinet/Case Material: Metal
Color: Black
Size
Height: 107 mm / 4.21 inches
Width: 479 mm / 18.86 inches
Depth: 406 mm / 15.98 inches
Weight: 6.4 kg / 14.11 lbs
Shipping Information
Package Height: 150 mm / 5.91 inches
Package Width: 453 mm / 17.83 inches
Package Depth: 523 mm / 20.59 inches
Package Weight: 7.4 kg / 16.31 lbs
